12-13 / 32
SOLUTION 500/500SB
This is a highly efficient clean burning convection stove that brings elegance and
comfort to any home. The hot air-wash system gives fascinating flame patterns and
crystal clear glass, and its convection casing reduces the required clearance from
combustibles to 300mm each side. The casing is available in a stainless steel option
to give a contemporary look. The 500SB has the extra benefit of a combined boiler.
Optional Features
Available in a range of seven colours to
compliment your decor.
Satin chrome door handles and fittings.
Optional top or rear flue outlet.
External air system, for a direct
connection to an outside air supply.
Style Options
12
Clearview Stoves
Clearview Stoves
13
Boiler options
Solution 500SB 10,000Btu
- The boiler is located above the firebox
and is heated by the flue-gases. This
results in the glass remaining cleaner than
conventional boiler stoves.
- Rear 150mm flue outlet.
- The boiler has four 28mm connections.
Solution 500 8kW heat output
Solution 500SB 6kW heat output to room
plus 10,000Btu (3kW) to boiler
One large Clearview double-glazed door
that gives an impressive view of the flames.
Clearview hot air-wash system for really
clean burning without fuss or pampering.
Independent up draft and down draft
air distribution system for maximum
response and control
Refractory lining, and tertiary air supply,
promoting super clean combustion.
Multi-fuel grate, for easy lighting and
rapid response.
Heavy steel construction – welded inside
and out for durability and long life.
Convection casing ensures a lower surface
temperature, allowing closer installation to
vulnerable surfaces.
All “wear and tear” stove parts are easily
replaceable.
Solid brass knobs and door handles.
Stainless steel ash pan for long life and
easy ash removal.
Rotary grate for easy riddling.
Adjustable hinges and door catch to
maintain air tightness throughout the life
of the door seals
Base plate to provide additional floor
protection.
Hotplate surface for coffee pot or kettle.
Built in fuel store for logs or morning
kindling.
Takes up to 15 inch logs.
Solution 500
with plain sides
Solution 500SB
with plain sides
Solution 500
with stainless
steel side panels
Solution 500SB
with stainless
steel side panels
